| Item | U-eBank-261LHYB2 |
| Battery Parameters | |
| Number of battery packs | 10 |
| Rated voltage | 832V |
| Voltage range | 728 ~ 923V |
| Rated energy | 261kWh |
| Max. continuous charge/discharge current | Charge 157A, Discharge 314A |
| Depth of discharge | 90% |
| Cycle life | 6000 Times |
| Photovoltaic Parameters | |
| Maximum PV input power | 120kW |
| Rated input voltage | 600V |
| Maximum input voltage | 850Vdc |
| MPPT voltage range | 200 ~ 850Vdc |
| Photovoltaic input current | 50A × 8 |
| AC Side Parameters | |
| AC rated output power | 125kVA |
| AC maximum output power | 125kVA |
| AC maximum output current | 314A |
| Output voltage | 3L/N/PE; 230/400V |
| Frequency | 50/60Hz |
| Equivalent voltage transformer | Option (default no transformer) |
| THDi | ≤3% |
| STS function | Have (switching time) <10ms |
| System Parameters | |
| Size (W × D × H) | 1800 × 1250 × 2000 / 2550 × 1300 × 2000mm |
| Weight | About 3,350 kg |
| Communication | CAN/RS485 |
| Extinguishing and protection | Pack level + cabinet level |
| Expand | Support for capacity expansion of 1,075 kWh |
| Case protection grade | IP54 |
| Cooling | Air cooling / Liquid cooling |
| Ambient temperature | -30 ~ 60℃ |
| Humidity | 0% ~ 100% RH |
| Altitude | <2000m |
