| Item | HC1075P |
| AC (On-grid) | |
| Rated Power | 500kW |
| Maximum Current | 794A |
| Rated Voltage | 400V |
| Wiring Method | 3P4L+PE |
| Frequency | 50Hz/60Hz |
| Power Factor | 1 (Leading) ~ 1 (Lagging) |
| THDi | ≤3% (Rated Power) |
| AC (Off-grid) | |
| Rated Power | 500kW |
| Rated Voltage | 400V |
| Maximum Current | 794A |
| Wiring Method | 3P4L+PE |
| Frequency | 50Hz/60Hz |
| THDu | ≤2% (Linear Load) |
| Battery | |
| Battery Type | LiFePO4 |
| Battery Cell | 3.2V/280Ah |
| Battery Pack Configuration | 1P16S × 5 |
| Battery Pack Quantity | 15 Packs/Cluster × 5 |
| Rated Current | 140A × 5 |
| Voltage Range | 648 ~ 864V |
| Rated Capacity | 1075.2kWh |
| PV | |
| Max. Usable PV Input Power | 400kW |
| Max. Input Current | 130A × 8 |
| Max. Short Circuit Current | / |
| Max. Input Voltage | 900V |
| MPPT Voltage Range | 250V ~ 800V |
| Start-up Voltage | 250V |
| MPPT Number | 8 |
| System | |
| Weight | 15T |
| Dimensions (W/D/H) | 6058 × 2438 × 2896mm |
| Maximum Efficiency | ≥85% |
| Air Conditioning Power | 25kW (Cooling), 9kW (Heating) |
| Temperature | -20℃ ~ 50℃ (De-Rating Over 45℃) |
| Humidity | 5% ~ 95% RH (Non-Condensation) |
| Protection Level | IP54 |
| Anti-corrosion Rating | C4 |
| Cooling Method | Air Cooling |
| Noise | ≤75dB |
| Altitude | 2000m (>2000m Derating) |
| Display | HMI |
| Fire Protection | FM-200 |
| Communication | Ethernet |
| Certification | CE, UN38.3 |
| Charge/Discharge Rate | 0.5C |
| Depth Of Discharge | 90% DOD |
| Cycle Life | ≥6000 Cycles (80% SOH @ Standard) |
