| Item | HC215P |
| AC (On-grid) | |
| Rated Power | 105kW |
| Maximum Current | 167A |
| Rated Voltage | 400V |
| Wiring Method | 3P4L+PE |
| Frequency | 50Hz/60Hz |
| Power Factor | 1 (Leading) ~ 1 (Lagging) |
| THDi | <2% (Rated Power) |
| AC (Off-grid) | |
| Rated Power | 105kW |
| Rated Voltage | 400V |
| Maximum Current | 167A |
| Wiring Method | 3P4L+PE |
| Frequency | 50Hz/60Hz |
| THDu | <3% (Linear Load) |
| Battery | |
| Battery Type | LiFePO4 |
| Battery Cell | 3.2V/280Ah |
| Battery Pack Configuration | 1P16S |
| Battery Pack Quantity | 15 Packs/Cluster |
| Rated Current | 140A |
| Voltage Range | 648 ~ 864V |
| Rated Capacity | 215.04kWh |
| PV | |
| Max. Usable PV Input Power | 120kW |
| Max. Input Current | 50A × 4 |
| Max. Short Circuit Current | 60A × 4 |
| Max. Input Voltage | 900V |
| MPPT Voltage Range | 200V ~ 850V |
| Start-up Voltage | 250V |
| MPPT Number | 4 |
| System | |
| Weight | <3T |
| Dimensions (W/D/H) | 1800 × 1100 × 2250mm |
| Maximum Efficiency | ≥85% |
| Air Conditioning Power | 3kW (Cooling), 2.5kW (Heating) |
| Temperature | -20℃ ~ 50℃ (De-Rating Over 45℃) |
| Humidity | 5% ~ 95% RH (Non-Condensation) |
| Protection Level | IP54 |
| Anti-corrosion Rating | C4 |
| Cooling Method | Air Cooling |
| Noise | ≤75dB |
| Altitude | 2000m (>2000m Derating) |
| Display | LCD |
| Fire Protection | Aerosol |
| Communication | Ethernet |
| Certification | CE, UN38.3 |
| Charge/Discharge Rate | 0.5C |
| Depth Of Discharge | 90% DOD |
| Cycle Life | ≥6000 Cycles (80% SOH @ Standard) |
