Smart Dock streamlines solar energy systems by combining load and power control in a single device. It ensures proper connections between microinverters, batteries, and loads for efficient, reliable grid-tied operation. With its built-in Smart Gateway Pro, the Smart Dock enables remote monitoring, maintenance, and management, allowing you to track your system's status at any time.

Smart Dock streamlines solar energy systems by combining load and power control in a single device. It ensures proper connections between microinverters, batteries, and loads for efficient, reliable grid-tied operation. With its built-in Smart Gateway Pro, the Smart Dock enables remote monitoring, maintenance, and management, allowing you to track your system's status at any time.
Smart Dock-7.2 Component ListUnitSpecifications
Gateway/EQ-MU series ×1
Grid-side Circuit Breaker/NXBLE-63E 2P C63 30Max×1
Load-side Circuit Breaker/NXB-63E D63 2P×1
Microinverter Circuit Breaker/NXB-63E C20 2P×2
SPD/NXU-IIG E 40KA/385V 2P×1
Meter (Optional)/ADL200N-CT/D10×3
Electrical Parameters
Rated voltageV220/230/240 AC
Operating Voltage Range(L to N)V184-276 AC
Rated frequencyHz50/60
Maximum frequency rangeHz45-65
Maximum number of PV strings/2
Maximum PV current per stringA20
Nominal CT currentA80
Overvoltage Category/III
General Parameters
Operating temperature℃-30~50
Enclosure protection class/IP65
Altitudem3000
Dimensionsmm400×595×110
WeightKg6.5
Communication mode/PLC, RS485, WiFi, 4G
Smart Dock-7.2 Component ListUnitSpecifications
Gateway/EQ-MU series ×1
Grid-side Circuit Breaker/NXBLE-63E 2P C63 30Max×1
Load-side Circuit Breaker/NXB-63E D63 2P×1
Microinverter Circuit Breaker/NXB-63E C20 2P×2
SPD/NXU-IIG E 40KA/385V 2P×1
Meter (Optional)/ADL200N-CT/D10×3
Electrical Parameters
Rated voltageV220/230/240 AC
Operating Voltage Range(L to N)V184-276 AC
Rated frequencyHz50/60
Maximum frequency rangeHz45-65
Maximum number of PV strings/2
Maximum PV current per stringA20
Nominal CT currentA80
Overvoltage Category/III
General Parameters
Operating temperature℃-30~50
Enclosure protection class/IP65
Altitudem3000
Dimensionsmm400×595×110
WeightKg6.5
Communication mode/PLC, RS485, WiFi, 4G
